D-Link DI-707P [38/74] Installing the print server software continued
![D-Link DI-707P [38/74] Installing the print server software continued](/views2/1045352/page38/bg26.png)
38
Select the destination folder.
Click Next
After rebooting your computer, the software installation procedure is finished.
Installing the Print Server Software (continued)
Click OK
Click Finish
Click Browse to
select a destination
folder
Select the
option for
restarting the
computer.
