39
Configuring on Windows 98SE/ME Platforms
After you finish the software installation
procedure, your computer will be capable of
network printing provided by the DI-707P. For
convenience, we call the printer connected to
the printer port of the DI-707P a print server.
On a Windows 95/98 platform, open the
Printers window in the My Computer menu.
Now, you can configure the print server of
the DI-707P:
Find out the corresponding icon of your
print server, for example, the HP
LaserJet 6L. Right click on that icon,
and then select Properties.
The screen at right appears.
Choose the “PRTmate: (All-in-1)”
from the list attached at the Print
To item. Be sure that the Printer
Driver item is configured to the
correct driver of your printer server.
Type in the IP address of the
DI-707P.
Click on the
Details tab
Click Port Settings
Click OK
