DGS-1210/ME Metro Ethernet Switch CLI Reference Guide

485

config cpu_access_profile

Purpose To configures the settings of cpu access profiles.

Syntax

config cpu_access_profile [profile_id <value 1-3>] [add

access_id [ auto_assign | <value 1-5>]] [ ethernet {vlan <vlanid

1-4094> | source_mac <macaddr> | destination_mac <macaddr>

| 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>} | ip

{source_ip <ipaddr> | destination_ip <ipaddr> | dscp <value 0-

63> | [icmp {type <value 0-255> code <value 0-255> } | igmp

{type <value 0-255>} | tcp {src_port <value 0-65535> | dst_port

<value 0-65535> | urg | ack | psh | rst | syn | fin} | udp {src_port

<value 0-65535> | dst_port <value 0-65535> | protocol_id <value

0-255>] | ipv6 {class | source_ipv6 <ipv6addr> |

destination_ipv6 <ipv6addr>} [port [<portlist> | all] [permit |

deny]] delete access_id <value 1-5>]

Description

The config cpu_access_profile command configures the settings

of cpu access profiles.

Parameters

profile_id <value 1-3> – Specifies the cpu access profile to be

configured.

[add | delete] – Add or delete the profile id.

access_id [<value 1-5> | auto_assign] – Specifies the access id

value or use auto assign.

ethernet – Specifies that the Switch examine only the layer 2 part of

each packet to determine if it is to be filtered or forwarded based on

one or more of the following:

• 802.1p <value 0-7> – Specifies the 802.1p value. The range

is between 0 and 7.

• destination_mac <macaddrf> – Specifies the destination

MAC address.

• ethernet_type – Specifies the Ethernet type mask.

• <portlist> – Specifies the port or ports to be configured.

• source_mac <macaddr> – Specifies the source MAC

address.

vlan <vlanid 1-4094> – Specifies the VLAN id.

ip – Specifies that the Switch examine the IP fields in each packet to

determine if it will be either forwarded or filtered based on one or

more of the following:

• destination_ip <ip_addr> – Specifies the destination IP

address.

• dscp <value 0-63> – Specifies the DSCP value.

icmp – Specifies that the Switch examines the Protocol field in

each frame’s IP header , and that the value must be 1 (Internet

Control Message Protocol- ICMP) for the action to take place.

• code <value 0-255> –Specifies that the Switch examine

each frame’s ICMP code field.

• type <value 0-255> –Specifies that the Switch examine each

frame’s ICMP Type field.

igmp – Specifies that the Switch examine each frame’s protocol

field and it must be 2 (Internet Group Management Protocol-

IGMP) for the action to take place.

• igmp_type <value 0-255> – Specifies the IGMP type.

<portlist> – Specifies the port or ports to be configured.

protocol_id <value 0-255> – Specifies the protocol id.
