- OPERATING INSTRUCTION

3. Turning on the dental operatory

Pressthemainswitch(f1)onthedentalchaircasingandcheckonthe

controlconsolethat:

• “POWER”led(g)on

 -equipmenton

 -pneumaticsystemconnected

 -watersystemconnected

• “POWER”led(g)off

 -equipmentoff

 -pneumaticsystemdisconnected

 -watersystemdisconnected

4. Dental chair operation

NEW SKEMA dental chair

ThedentalchairNEWSKEMAcanbemovedasfollows:

•Chairseatup/down

•Backup/downwithinclinationofthechairseat(Trendelemburgcompen-

sated)

Thedentalchaircanbeoperatedfromthefollowingplaces:

•Instrumentboard[ a ](seepar.5).

•Multifunctionfootcontrol[ b ](seepar.5.2).

•Assistant’sboard[ c ](seepar.6).

Thefootrest[r]canbepulledoutbyabout10cm.

Dental chair movement shutdown

Withtheinstrumentsinrestposition,youcandisablethedentalchair

movements(seeparagraph5.1.1.2.9.).

Themovementdisablingisshownonthecontrolpaneldisplaybythe

relevanticon(A).
