SKEMA 6 / SKEMA 8

- OPERATING INSTRUCTION

5.1. Doctor’s control console

TheSkema6andSkema8seriesdentalunitshaveadentist’sconsolewith

touchscreeninterfacecomposedofaglassmulti-touchcapacitivetouch

panelwithrearprojectionanda5.7”WideTFTcolourdisplaywithLED

backlighting,resolution640x480pixelsand16.7millioncolours.

Description of the capacitive buttons:

Touchscreendisablebutton.

Description of the icon buttons visible on the touch panel:

IconbuttontocalluptheGENERALSETTINGSmenu.

Iconbuttontochangeoperator.

Iconbuttontocallupthewarningicons.

Operatinglampon/officonbutton.

 Iconbuttontoreducetheoperatinglampbrightness.

Cupwaterdeliverycontroliconbutton.

Assistantcalliconbutton.

 S.S.S.systemactivation/deactivationiconbutton.

Anticlockwisebowlmovementcontroliconbutton.

 (activeonlywithmotor-drivenbowl).

Clockwisebowlmovementcontroliconbutton.

 (activeonlywithmotor-drivenbowl).

Bowlwaterdeliverycontroliconbutton.

Dentalchairfunctionstorageiconbutton.

Emergencypositionrecalliconbutton.

Resetpositionrecalliconbutton.

Rinsingpositionrecalliconbutton.

NOTE: Operation of the dental chair movement icon buttons:

• Buttonpressedshortly:setpositionautomaticallyreached

• Buttonhelddown:positionedreachedbyhand.

Seatupandprogrammedposition1recalliconbutton.

Backrestupandprogrammedposition2recalliconbutton.

Seatdownandprogrammedposition3recalliconbutton.

Backrestdownandprogrammedposition4recalliconbutton.
