5.8. C-U2 and C-U2 PRO intraoral camera system
TheC-U2dentalcamerasystem,completewithanextremelylightweightergonomichandpiece,isspeciallydesignedforsimpleandwell-conceivedusability
inexaminingtheoralcavity.Auto-exposureandxedfocusfeaturesprovideeasyoperation.Thissystemisdesignedtoallowthedentisttomoreefciently
showandexplaintopatientsalloralconditionsandreasonsforplannedtreatment.TheC-U2systemallowstakinghigh-denition(1280x720)liveimagesof
thesectioninquestionthroughthetouchofangertiponthetouch-sensitiveareaofthehandpiece.Theliveintraoralimagesaredisplayedonthemonitor
orPersonalComputer.
WARNING!
The camera may be used as a tool to aid in diagnosis; however, the result must always be supported with visual examination and/or other diagnostic
indications. Evaluations and conclusions based only on the image taken by the camera may be poor as the colours and shapes, electronically
processed, may not perfectly correspond to the actual ones.
Warnings for use.
WARNING!
•TheexternalPCandtheexternalmonitormustbeofmedicalgrade,namelytheyhavetobecertiedandcomplywiththeIEC60601-1Standard3rdEd.
Theyhavetobeabletoensureadoubleinsulationlevelforbothpatient(2MOPP)andoperator(2MOOP):-withrespecttothepowermains;-toallthe
I/Oports(USB,LAN)suppliedwithSafetyExtraLowVoltage(SELV).
•Eventhoughtheelectromagneticeldirradiatedbythedeviceisinsignicant,itisadvisablenottouseitinproximityoflifesupportequipment(e.g.pace-
makersorheartstimulators)accordingtothespecicationsincludedintheusermanualofsuchequipment.
•Thedisposableinfectioncontrolsheathsmustbeusedwiththedevice.Changethesheathforeachnewpatient.
•Afterputtingonanewdisposableinfectioncontrolsheath,checkitoverbeforeusingthecamera,makingsureitisnottornanywhere.Ifitis,takeitoffand
putonanewone.
•Donotplacethehandpieceinliquidsorinautoclaveunderanycircumstances.
•Storethehandpieceinacleandryarea.
•Donotbendtheconnectingcableexcessively.
•Beextremelycarefulnottodropthehandpieceanddonotexposeittoexcessivevibrations.
•Neveruseadamagedhandpiece.Makesurethecameraisingoodconditionandhasnosharpedgesbeforeattemptingtouseit.Ifindoubt,donotuse
thehandpiece,carefullyputitaway,andcontacttechnicalassistance.
•Beforestartingtheequipment,checktheconditionofthelensprotection.
•Donotaimthelightbeamattheoperator’sorpatient’seyesduringoperation.
•Duringcontinuoususe(example,morethan10consecutiveminutes),thetemperatureofthecamera’stipusuallyincreasessignicantly;ifthisisuncomfor-
table,putthehandpieceinitsholderforafewminutestoallowthelightsourcetocooldown.Whenthecameraneedstobeusedforaprolongedtime,
reducelightbrightnessusingthecursorontheOSDControlPanel(seeparagraph5.8.1.).
•Ifleftrunningforextendedperiods,makesurethetemperatureofthetipisacceptablebeforeattemptingtousethecamera.Brieytouchtheclearplastic
partwithyourngertipbeingcarefulnottotouchthelensinthemiddle.
•Donotattempttobend,pullorremovethehandpiece.
Connecting the handpiece.
AttachthehandpieceofcameraC-U2(a)totheendofthecordandtighten
theringnut(b).
WARNING!
Makesurethecordisrmlyscrewedontothehandpiece.
Use of the camera.
•Placetheinstrumentinitsworkingposition.
Now camera is activated and is in LIVE mode (monitor shows "moving"
images)orFREEZEmode(monitorshowsasnapshot).
•ThemainiconbuttonsavailableontheTOUCHDISPLAYare:
Colourproleadjustment
(onlywithcameraextractedandsettoLIVE)
CameraLEDturningon/off
(onlywithcameraextracted)
Activation/deactivationofMIRRORfunction
(onlywithcameraextractedandsettoLIVE)
Overturnthecapturedimage
Turncapturedimageclockwise
Recallmaincontrolsofmainscreen
Deletethecapturedimage
Movethecaptured images to a folder of the internal
memoryorUSB(onlywithcamerainrestposition)
