5
SKEMA 6 / SKEMA 8
- OPERATING INSTRUCTION
5
EN
1.2.2. Environmental conditions
Theequipmentistobeinstalledinroomsthatsatisfythefollowingrequirements:
•temperaturebetween10and40°C.
•relativehumiditybetween30and75%.
•atmosphericpressurerangingfrom700to1060hPa.
•altitude≤3000m;
•airpressureenteringequipmentrangingfrom6to8bar.
•waterhardnessenteringequipmentnotover60mg/l.
•waterhardnessattheequipmentinletmustnotbeabove25°f(Frenchdegrees)or14°d(Germandegrees)foruntreateddrinkingwater.Forwater
withahigherhardnessdegree,itisrecommendedtosoftenwateruntilitreachesahardnessdegreebetween15and25°f(Frenchdegrees)or
between8.4and14°d(Germandegreees);
•waterpressureenteringequipmentrangingfrom3to5bar.
•watertemperatureenteringequipmentnothigherthan25°C.
1.2.2.1. Transport and packaging conditions
•Temperature:from-10to70°C;
•Relativehumidity:from10%to90%;
•Atmosphericpressure:from500to1060hPa.
1.2.3. Warranty
CEFLAs.c.standsbehinditsproductswarrantingsafety,reliabilityandperformance.
Thewarrantyisvalidonlyunderthefollowingterms:
•Theconditionsgivenonthewarrantycerticateareobserved.
•Performingannualscheduledmaintenance.
•Theequipmentisusedonlyasinstructedinthismanual.
•TheelectricalwiringintheroominwhichtheequipmentisinstalledmustconformtoIEC60364-7-710(standardsforelectricalwiringinmedical
anddentalofces).
•A3x1.5mm
2
lineprotectedbyabi-polarcut-outthatconformstoapplicablestandards(10A,250V,distancebetweencontactsatleast3mm)must
beusedtofeedtheequipment.
WARNING!
The color of the three wires (POWER, NEUTRAL and EARTH) should satisfy the requirements of current standards.
•Installation,repairsand,ingeneral,anyotheroperationsrequiringthecasingtobeopenedaretobeperformedexclusivelybypersonnelauthorized
by CASTELLINI.
1.2.4. Disposing the equipment when no longer used
AssetoutinDirectives2011/65/EUand2012/19/EU,ontherestrictionsoftheuseofcertainhazardoussubstancesinelectricalandelectronic
equipmentalongwithcollection,treatment,recyclinganddisposalofwasteelectricalandelectronicequipmentthelattermustbetreatedasmunici-
palwaste,thereforesortedandcollectedseparately.Whennewequipmentofequivalenttypeispurchasedthewasteequipmentshouldbereturned
tothedistributoronaone-to-onebasisfordisposal.Asfarasreuse,recyclingandotherformsofwasterecoverymentionedaboveareconcerned,
themanufacturerisresponsiblefortheactionsspeciedbyindividuallocallaws.Efcientcollectionofsortedwasteseparatelytorecycleandtreat
wasteelectricalandelectronicequipmentaidsinpreventingnegativeenvironmentalimpactswhileprotectinghumanhealth.Inadditionitfacilitates
recyclingofthematerialsusedtoconstructtheequipment.Illegalwastedisposalcarriesheavynesdenedbylocallaws.
WARNING!
The crossed out wheeled bin placed on the equipment indicates that the waste equipment must be collected separately from other waste.
1.3. Safety rules
WARNING!
• All equipment is permanently installed.
Dependingonthetypeofchairtheunitcomeswith,refertotheinstallationDATAgiveninparagraph“Specications”.
CEFLA s.c. shall not be held liable for any personal injury or equipment damage resulting from failure to heed the precaution given above.
• Floor condition
Theoor(continuous)shouldmeettheload-bearingcapacitysetforthbyDIN1055,sheet3.Theweightofthedentalunitincludinga190kgpatient
isabout350kg/sq.m.
•Thisdevicemaynotbemodiedinanywaywithouttheauthorisationofthemanufacturer.
Ifthedeviceismodied,appropriateexaminationsandtestsneedtobeconductedinordertoensurecontinuedsafeuse.
CEFLA s.c. shall not be held liable for any personal injury or equipment damage resulting from failure to heed the precaution given above.
• Dental chair
Themaximumchaircapacityis190Kg.Thisweightmustneverbeexceeded.
• Tray holders
Themaximumweightsthatcanbeheldmustneverbeexceeded:
-Instrumenttrayattachedtotheinstrumentboardmaximumallowableload2Kg,evenlydistributed.
-Instrumenttrayattachedtotheinstrumentboardmaximumallowableload1Kg,evenlydistributed.
-Auxiliaryinstrumenttray,maximumallowableloadontray3.5Kg(nox-raylmviewer)or2.5Kg(withx-raylmviewer).
