SKEMA 6 / SKEMA 8

- OPERATING INSTRUCTION

5.1.2.Settingthedentalchair’s“rinse”and“home”positions

Thissettingisspecicforeachoperator.

Performthefollowingoperationsfromthemainscreen:

• Bringthedentalchairintothedesiredpositionwiththemanualmovements

buttons.

NOTE: if the bowl is motor-driven, you can also store the bowl

position.

• Activatestoragemodebypressingthe

buttonforatleast2seconds.

 Storagemodeactivationissignalledbyashortbeepandbythededicated

icon(A )ontheTOUCHDISPLAY.

NOTE: Hold down button for at least 2 seconds to quit without

saving the changes made.

• Pressbuttons“Automaticreturn”or“Rinseposition”toassigntheposition

tothebutton.

 Theicon(B )referringtotheprogramselectedwillappearontheTOUCH

DISPLAYtoconrmthatithasbeenstored.

NOTE: The “Rinse position” button brings the backrest and seat

into the rinse position.

Whenbutton“Rinseposition”ispressedagain,thebackrestandseatreturn

tothepreviousposition.

5.1.3. Programming the chair positions 1, 2, 3 and 4

Thissettingisspecicforeachoperator.

Performthefollowingoperationsfromthemainscreen:

• Bringthedentalchairintothedesiredpositionwiththemanualmovements

buttons.

• Activatestoragemodebypressingthe buttonforatleast2seconds.

NOTE: Storage mode activation is signalled by a short beep and

by the dedicated icon ( A ) on the TOUCH DISPLAY.

• Pushthe1,2,3or4keystoassociatetherelevantpositiontothekey

(e.g.3).

NOTE: The icon ( B ) referring to the program selected (e.g. 3) will

appear on the TOUCH DISPLAY to conrm that it has been stored.

NOTE: To call up a set position simply briey press the button

assigned to the relative position.
