SKEMA 6 / SKEMA 8
- OPERATING INSTRUCTION
81
EN
8. Accessories
8.1. Operating lamp
Theoperatinglampcomesin2models:
Lamp with halogen light source – model VENUS PLUS.
Lamp with LED light source – model VENUS PLUS-L.
Theinstructionsforuseandmaintenanceofthelampsareavailablein
PDFformatandcanbedownloadedfromthedownloadareaofthewebsite
www.castellini.com.
NOTE: During the automatic movements of the dental chair, the
lamp automatically turns off to prevent blinding the patient.
8.2. Monitor on lamp pole
Theinstructionsforuseandmaintenanceofthemonitorareincludedwith
thedentalunit.
8.3. Negatoscope for panoramas
Anx-raylmviewerforpanoramicx-rayscanbemountedonallCPversion
instrumentboards.
Thescreendimensionsareasfollows:H=210mm,L=300mm.
Peraccendereilnegatoscopioèsufcienteagiresull'appositointerruttore(a):
=negatoscopeon
=negatoscopeoff
8.4. Air/water/230V quick-connect couplers
Theair/water/230Vquick-connectcouplersareplacedtothesideofthe
electricalbox.
WARNING!
Shut off the equipment before attempting to connect or disconnect
the air/water outlets.
Technicalspecications.
•Poweroutlet:230VAC2AinaccordancewithIEC/EN60320-2-2/F(only
ondentalunitswith230VACpowersupply).
•Airquick-connectcouplerpressure:6Bar.
•Waterquick-connectcouplerpressure:
- municipalwater,2.5Bar
-withS.S.S.system,1,8Bar
-withM.W.B.system,3Bar
•Waterquick-connectcouplerdeliveryrate:
-municipalwater,1800ml/min
-withS.S.S.system,950ml/min
-withM.W.B.system,400ml/min
NOTE: with S.S.S. system: to use the quick-coupling with mains
water, disable the distilled water tank (see Paragraph 7.2.)
