SKEMA 6 / SKEMA 8

- OPERATING INSTRUCTION

Warning icons.

Touchingtheiconbutton

onthetouchdisplay,youcanatanytime

viewthewarningiconsthatshowtheoperatingstatusofthedentalunit.

Thewarningiconsviewablearethefollowing:

M.W.B. systemrunning.

Feedingwithdistilledwateractivated.

 Feedingwithmainswateractivated.

Peristalticpumpinsertedwiththedeliveredquantityofsalinesolution

equalto1.

Distilledwaterlevellow.

 Lowdisinfectantliquidinthetanktubing.

AUTOSTERIL cycleinprogress.

Suctiontubesbeingwashed.

Suctionstoppedduetofullcanister.

 Green:wirelessfootcontrolbatterycharged.

 Orange:wirelessfootcontrolbattery50%charged.

 Red:wirelessfootcontrolbatteryat.

 Green:wirelessfootcontrolconnectedandactive.

 Orange:wirelessfootcontrolconnectedbutnotactive.

 Red:searchingforconnectiontothewirelessfootcontrol.

Pantographarmbrakeengaged.

 Blue:COLDwater-to-glass.

 Orange:WARMwater-to-glass.

 Red:HOTwater-to-glass.

 Dentalchairpositionautomatedprogramme1.

 Dentalchairpositionautomatedprogramme2.

 Dentalchairpositionautomatedprogramme3.

 Dentalchairpositionautomatedprogramme4.

Dentalchairmovementsblocked.

Rinseautomatedprogrammechairposition.

 Homeautomatedprogrammechairposition.

Emergencyautomatedprogrammechairposition.

Dentalchairsavefunctionon.

Chairpositionmanuallysetup.

Reducedoperatinglampbrightness.
