12
English
Gloves for handling saw blades (saw blades shall
be carried in a holder wherever practicable) and
rough material.
15. The operator is adequately trained in the use,
adjustment and operation of the machine.
16. Refrain from removing any cut-offs or other parts
of the workpiece from the cutting area whilst the
machine is running and the saw head is not in the
rest position.
17. Never use the compound miter saw with its lower
guard locked in the open position.
18. Ensure that the lower guard moves smoothly.
19. Do not use the saw without guards in position, in
good working order and properly maintained.
20. Use correctly sharpened saw blades. Observe the
maximum speed marked on the saw blade.
21. Do not use saw blades which are damaged or
deformed.
22. Do not use saw blades manufactured from high
speed steel.
23. Use only saw blades recommended by HITACHI.
Use of saw blade comply with EN847-1.
24. The saw blades should be from 235 mm to 255 mm
external diameter ranges.
25. Select the correct saw blade for the material to be
cut.
26. Never operate the compound miter saw with the
saw blade turned upward or to the side.
27. Ensure that the workpiece is free of foreign matter
such as nails.
28. Replace the table insert when worn.
29. Do not use the saw to cut other than aluminium,
wood or similar materials.
30. Do not use the saw to cut other materials than those
recommended by the manufacturer.
31. Blade replacement procedure, including the method
for repositioning and a warning that this must be
carried out correctly.
32. Connect the compound miter saw to a dust
collecting device when sawing wood.
33. Take care when slotting.
34. When transporting or carrying the tool, do not grasp
the holder. Grasp the handle instead of the holder.
35. Start cutting only after motor revolution reaches
maximum speed.
36. Promptly cut OFF the switch when abnormality
observed.
37. Shut off power and wait for saw blade to stop before
servicing or adjusting tool.
38. During a miter or bevel cut the blade should not be
lifted until it has stopped rotation completely.
39. Take all the possibility of residual risks in cutting
operation into your consideration, such as the laser
radiation to your eyes, the inadvertent access to
moving parts on slide mechanical parts on machine
and so on.
59 mm × 144 mm
0° or
89 mm × 101 mm
Miter 45° 59 mm × 102 mm
Bevel Left 45° 41 mm × 144 mm
Compound (Bevel Left 45°, Miter 45°)
41 mm × 102 mm
Saw Blade Dimensions (oD × iD × Thickness) 255 mm × 30 mm × 2.3 mm
Miter Cutting Angle Right and Left 0° – 52°
Bevel Cutting Angle Left 0° – 45°
Compound Cutting Angle Miter (Right and Left) 0° – 45°
Voltage (by areas)* (110 V, 230 V)
Power Input* 1520 W
No-Load Speed 5000 min
–1
Machine Dimensions (Width × Depth × Height) 460 mm × 628 mm × 561 mm
Weight (Net) 12 kg (C10FCH2) / 11.9 kg (C10FCE2)
Maximum output Po<3 mW Class Laser Product
(Iambda) 654 nm
Laser medium Laser Diode
Max. Cutting
Capacity
Height × Width
Laser Marker
(Only Model C10FCH2)
SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) 255 mm TCT Saw blade (mounted on tool) ............. 1
(2) Dust bag ...................................................................... 1
(3) 10 mm Box wrench .................................................... 1
(4) Vise Assembly ............................................................ 1
(5) 4 mm Hex.bar wrench (only C10FCH2) .................... 1
(6) Sub Fence (B) ............................................................. 1
(7) Flat screw .................................................................... 1
(8) M6 Nylon nut .............................................................. 1
(9) Plate (A) ....................................................................... 1
(10) Holder (B) .................................................................. 1
(11) Side handle ............................................................... 1
Standard accessories are subject to change without
notice.
01Eng_C10FCH2_WE_7L 3/11/09, 9:5212
