Operating Manual for UTD2000/3000

1. Use horizontal SCALE knob to alter horizontal

time base gear then observe alternation of status

information. To rotate horizontal SCALE knob to

alter “s/div” time base gear so as to show

corresponding variation of time base gear displa

for corresponding channels of status bar

Horizontal scanning speed steps from 2ns/di

s/div by way of 1 mode

Note: Horizontal scanning time base gear varies

for UTD2000/3000 series digital storage

oscillograph due to different models

㨪

㧙㧙50 2

2. Use horizontal POSITION knob to adjust

horizontal position of signals in waveform window

To use horizontal POSITION knob to control trigger

displacement of signals. Horizontal movement of

waveform with knob can be observed when rotatin

horizontal POSITION knob for application for

trigger displacement

3. Please press [MENU] button for 5.7-inc

oscillograph (and press [HORI MENU] button for 7-

inch oscillograph) to display Zoom menu. Please

press [F3] to open view window extension under

this menu then press [F1] to close view window

extension and return to main time base. Hold off

time can be set under this menu
