Oper ating Manual for UTD2000/3000

Please press [F2] to set band width limitation to ON

for great attenuation of high-frequency component

and noise of more than 20MHz contained b

measured signals. Waveform display is also show

in following figure

Figure 2 5Waveform display when openin

bandwidth limit

It has to set probe attenuation coefficient i

operation menu of channel to coordinate wit

attenuation coefficient setup of probe. Probe

coefficient in channel menu shall be set to 10× if

probe attenuation coefficient is 10:1. It has to

analogize to guarantee correct voltage

Volt/grid gears of vertical deflection coefficient can

be divided into coarse tuning and fine tuning

Please refer to following figure for setup and

vertical gear when using 10:1 probe

㧙

㧦3. Setup of multiplying factor for probe

bandwidt

limit

Probe

attenuatio

coefficient

Figure 2 Probe attenuation coefficient shown

in channel m en

㧙6
