Operating Manual for UTD2000/3000

Trigger point can be restored to vertical m iddle

point quickly by short-cut key of [SET TO ZERO] so

as to restoring displacement of trigger point to

horizontal zero point short-cut key. Users can also

adjust horizontal position of signal in waveform

window by rotating horizontal knob

Term explanatio

Trigger point: It refers to position of actual trigger

point by comparing with middle point of storage

instrument. Users can move trigger horizontally b

rotating horizontal POSITION knob

Hold off: It refers to interval to start up trigger

circuit again

Hold off time can be set by rotatin

multi-purpose

knob controller

s shown in Figure 1 there is 1 knob and

(or 2) keys in control area of trigger menu. Please

be familiar with setup of trigger system gradually as

foll ows

POSITIO

Elementary understanding of trigger system

㧙11

5.7-inch screen 7-inch scree

Figure 1-1

Trigger men

Figure 1 Trigger menu on the panel㧙11
