Measured signal is a sine signal with DC component

by taking exerting signal to CH1 channel as a

example

To press F1 to select AC and AC c oupling mode. D

component contained by measured signal will be

obstructed. Waveform display is shown in followin

figure

Press F1 to DC to pass through DC and A

components of measured signals of CH1 channel

Waveform display is also shown in following figure

Figure 2 2 Synchronous display of DC and A

components of signal

Press F1 to select grounding and set channels to

grounding mode. DC and AC components

contained by measured signals will be obstructed.

Waveform display is shown in following figure

displayed on the screen

Setup of channel couplin

㧦

Oper ating Man ual for UTD2000/3000

Figure 2 Jammed DC component of signal㧙1

Setup of

C couplin

DC couplin

setup
