Uni-T UTD2052CEX [70/120] Operating manual for utd2000 3000

Operating Manual for UTD2000/3000

Form 2-23 By detectio

Function menu

Setup

Descriptio

Detection status

Ope

Open/close information of waveform pass/fail times

Information source

CH1

MAT

Ref

RefB

Select CH1 as detected signal source

Select CH2 as detected signal source

Select MATH as detected signal source

Select RefA as detected signal source

Select RefB as detected signal source

Output conditions

Pass

Pass/Halt

Fail/Halt

Fail

Output concurrency prompt when detecting waveform pass

;

Output and pause when detecting waveform pass

;

Output and pause when detecting waveform fail

;

Output concurrency when detecting waveform fail

;

Template set up

Refer to Form

2-24 for details

Enter into template setup menu

Retur

Return to previous menu
