Operating Manual for UTD2000/3000

Trigger control

Trigger mode: Edge, pulse width, video and ALT TRIG

;

Edge trigger: Trigger when edge of trigger signal reaches a certain given level

Pulse width trigger: Trigger when pulse width of trigger signal reaches certain set trigger conditions

Video trigger: Carry out field or line trigger for standard video signals. (UTD2025CL/UTD2000EXseriesis

no such function.

)

LT TRIG: It is appropriate to trigger signal without frequency relevance. Various kinds of trigger menus

are also shown as follows

Edge trigger

Edge trigger mode is to trigger threshold value of input signal edge. That is, to trigger in ascending

descending edge of input signal when selecting “edge trigger”

Form 2-
