Adju stment of hold off time

djustment of hold off time can be used to observe complex waveform (such as pulse string series)

Inhibition time refers to waiting period of digital storage oscillograph to start up trigger circuit again

Digital storage oscillograph will not trigger until inhibition time ends during inhibition period. For instance

as shown in Figure 2-17, the first pulse among a group of pulse series shall be triggered to set inhibition

time to width of pulse string

Please refer to following form for hold off menu

Form 2-1

Operating Manual for UTD2000/3000

Function menu

Setup

Description

Main time base

1. To open main time base

;

2. To close view window extension according to main time base after openin

view window extension

View window extensio

To open extension time base

Hold off

To adjust inhibition time
