Fluke 43B [20/54] Adjusting the contrast
![Fluke 43B [20/54] Adjusting the contrast](/views2/1005303/page20/bg14.png)
Fluke 43B
Users Manual
16
Adjusting the Contrast
Adjust the contrast of the screen for optimal visibility of the screen.
1
Open the main menu.
2
3
4
Adjust the contrast until both
black and grey squares are
clearly visible.
5 Accept the new contrast.
Note
You can also adjust the contrast immediately after turning on the
Fluke 43B by using the up and down keys.
CONTRAST
INSTRUMENT SETUP
CONTRAST
