Fluke 43B
Users Manual
44
Electromagnetic Immunity
The Fluke 43B, including standard accessories, conforms with the EEC
directive 89/336 for EMC immunity, as defined by IEC1000-4-3, with the
addition of the following tables.
Disturbance with test leads TL24 or Current Clamp i400s
• Volts / amps / hertz
• Resistance, Capacitance
• Power
• Harmonics
Table 1
No visible disturbance E = 3 V/m E = 10 V/m
Frequency: 10 kHz - 27 MHz
Frequency: 27 MHz - 1 GHz
(-)
(-)
(-)
(-)
(-): no visible disturbance
Disturbance with test leads TL24 in scope mode
• V AC+DC (True RMS)
Table 2
Disturbance less than 1 %
of full scale
E = 3 V/m E = 10 V/m
Frequency: 10 kHz - 27 MHz
Frequency: 27 MHz - 200 MHz
Frequency: 200 MHz - 1 GHz
2 V/div - 500 V/div
500 mV/div - 500 V/div
(-)
10 V/div - 500 V/div
2 V/div - 500 V/div
5 mV/div - 500 V/div
(-): no visible disturbance
Table 3
Disturbance less than 10 % of
full scale
E = 3 V/m E = 10 V/m
Frequency: 10 kHz - 27 MHz
Frequency: 27 MHz - 200 MHz
Frequency: 200 MHz - 1 GHz
1 V/div
200 mV/div
(-)
5 V/div
1 V/div
(-)
(-): no visible disturbance
Ranges not specified in Tables 2 and 3 may have a disturbance of more than
10 % of full scale.
