Fluke 43B
Users Manual
42
Miscellaneous
Display
Useful screen area................................................72 x 72 mm (2.83 x 2.83 in)
Resolution.............................................................................. 240 x 240 pixels
Backlight .................................................... Cold Cathode Fluorescent (CCFL)
Power
External
Power Adapter ....................................................................................PM8907
Input Voltage ..............................................................................10 to 21V DC
Power .............................................................................................5 W typical
Internal
Rechargeable Ni-MH battery pack...................................................BP120MH
Voltage range ................................................................................4 to 6 V DC
Operating Time.................................................................................... 6 hours
Charging Time ........................................................5 hours with Fluke 43B off
60 hours with Fluke 43B on
Refresh cycle............................................................................ 12 to 19 hours
Memory
Number of screen memories ............................................................................ 20
Number of transient memories (temporary)...................................................... 40
Mechanical
Height x width x depth ................................. 232 x 115 x 50 mm (9.1 x 4.5 x 2 in)
Weight (including battery pack) .................................................... 1.1 kg (2.5 lbs)
Interface ................................................................................... Optically isolated
Supported Printers............. HP Deskjet
®
, Laserjet
®
, PostScript and Epson FX80.
Using HP PCL Protocol, Postscript, and Epson ESC/P Protocol.
Parallel via PAC91 (optically isolated Print Adapter Cable, optional).
Serial via PM9080 (optically isolated RS232 Adapter/Cable, optional).
To PC ...............................................................Dump and load settings and data
Via the OC4USB (optically isolated USB Adapter/Cable), or via the PM9080
(optically isolated RS232 Adapter/Cable, optional) using SW43W (FlukeView
®
Power Quality Analyzer software)
