![Fluke 43B [36/54] Ordering codes](/views2/1005303/page36/bg24.png)
Fluke 43B
Users Manual
32
Ordering Codes
The following tables list the user-replaceable parts for the Fluke 43B. For
additional optional accessories, see the ScopeMeter Accessories booklet. To
order replacement parts or additional accessories, contact your nearest service
center.
Replaceable Parts
Item Ordering
Code
Ni-MH Battery Pack (installed) BP120MH
Power Adapter/Battery Charger:
Universal Europe 230V, 50Hz
North America 120V, 60Hz
United Kingdom 240V, 50Hz
Japan 100V, 60Hz
Australia 240V, 50Hz
Universal 115V/230V *
* At delivery PM8907/808 is set to 230V. Check the
local line voltage before connecting the adapter. If
necessary, select the corresponding line voltage
with the slide switch on the adapter. A line plug
adapter complying with the applicable National
Requirements may be provided to alter the blade
configurations for a specific country.
PM8907/801
PM8907/8x3
PM8907/804
PM8907/806
PM8907/807
PM8907/808
Set of two Test Leads (Red and Black)
TL24
Set of two flat blade Test Pins (Red and Black)
TP1
Set of two 4mm Test Pins (Red and Black)
TP4
Set of two Large Alligator Clips (Red and Black)
UL1244
AC85A
Set of two Industrial Alligator Clips (Red and Black)
UL1244
AC20
Clamp-on AC Current Probe
i400s
Shielded Banana-to-BNC Adapter Plug
BB120
