744

Users Manual

106

AC Voltage Measurement

Frequency Range % of Reading + Number of Counts

1 Year 2 Year

20 Hz to 40 Hz 2% + 10 2% + 10

40 Hz to 500 Hz 0.5% + 5 0.5% + 5

500 Hz to 1 kHz 2% + 10 2% + 10

1 kHz to 5 kHz 10% + 20 10% + 20

Ranges : 1.1000 V, 11.000 V, 110.00 V, 300.0 V rms

Resolution: 11.000 counts in all ranges except 300 V; 3,000 counts on 300 V range.

Input Impedance: 5 M Ω and <100 pF

Temperature Coefficient: 10% of specification/°C in the ranges -10 to 18°C and 28 to 50°C

Input Coupling: ac

Maximum Input Voltage: 300 V rms

Minimum Input Voltage: 0.5 V above 1 kHz

Specifications apply for 10% to 100% of voltage range.
