Fluke 744 [121/138] Documenting process calibrator specifications

Documenting Process Calibrator

Specifications

111

Resistance Sourcing

Range Resolution % of Output + ohms

1 Year 2 Year

11.000 Ω 1 mΩ

0.01% + 0.02 0.02% + 0.02

110.00 Ω 10 mΩ

0.01% + 0.04 0.02% + 0.04

1.1000 kΩ 100 mΩ

0.02% + 0. 5 0.03% + 0.5

11.000 kΩ 1 Ω

0.03% + 5 0.04% + 5

Temperature Coefficient: (0.01% of f.s.)/°C in the ranges -10 to 18 °C and 28 to 50 °C

Maximum and Minimum Current through Source Resistance:

11 Ω Range: 8 mA dc max, 0.1 mA dc min

110 Ω Range: 8 mA dc max, 0.1 mA dc min

1.1 k Ω Range: 3 mA dc max, 0.01 mA dc min

11 k Ω Range: 1 mA dc max, 0.01 mA dc min

Common Mode Error: 0.008% f.s/(Common Mode Volt)

Maximum Input Voltage: 30 V dc
