Fluke 744 [123/138] Temperature thermocouples

Documenting Process Calibrator

Specifications

113

Temperature, Thermocouples

Type Range °C

Measure °C Source °C

1 Year 2 Year 1 Year 2 Year

E -250 to -200 1.3 2.0 0.6 0.9

-200 to -100 0.5 0.8 0.3 0.4

600 to 1000 0.4 0.6 0.2 0.3

N -200 to -100 1.0 1.5 0.6 0.9

-100 to 900 0.5 0.8 0.5 0.8

900 to 1300 0.6 0.9 0.3 0.4

J -210 to -100 0.6 0.9 0.3 0.4

-100 to 800 0.3 0.4 0.2 0.3

800 to 1200 0.5 0.8 0.2 0.3

K -200 to -100 0.7 1.0 0.4 0.6

-100 to 400 0.3 0.4 0.3 0.4

400 to 1200 0.5 0.8 0.3 0.4

1200 to 1372 0.7 1.0 0.3 0.4

T -250 to -200 1.7 2.5 0.9 1.4

-200 to 0 0.6 0.9 0.4 0.6

0 to 400 0.3 0.4 0.3 0.4
