Fluke 744 [124/138] Temperature thermocouples cont

744

Users Manual

114

Temperature, Thermocouples (cont)

Type Range °C

Measure °C Source °C

1 Year 2 Year 1 Year 2 Year

B 600 to 800 1.3 2.0 1.0 1.5

800 to 1000 1.0 1.5 0.8 1.2

1000 to 1820 0.9 1.3 0.8 1.2

R -20 to 0 2.3 2.8 1.2 1.8

0 to 100 1.5 2.2 1.1 1.7

100 to 1767 1.0 1.5 0.9 1.4

S -20 to 0 2.3 2.8 1.2 1.8

0 to 200 1.5 2.1 1.1 1.7

200 to 1400 0.9 1.4 0.9 1.4

1400 to 1767 1.1 1.7 1.0 1.5

C 0 to 800 0.6 0.9 0.6 0.9

800 to 1200 0.8 1.2 0.7 1.0

1200 to 1800 1.1 1.6 0.9 1.4

1800 to 2316 2.0 3.0 1.3 2..0

L -200 to -100 0.6 0.9 0.3 0.4

-100 to 800 0.3 0.4 0.2 0.3

800 to 900 0.5 0.8 0.2 0.3
