Fluke 744 [129/138] Top and bottom limits of ranges with auto range on

Documenting Process Calibrator

Specifications

119

Top and Bottom Limits of Ranges with Auto Range On

Range, dc V Measure Top of Range Bottom of Range

110 mV ±110.000 mV 0.000 mV

1.1 V ±1.10000 V ±0.10000 V

11 V ±11.0000 V ±1.0000 V

110 V ±110.000 V ±10.000 V

300 V ±300.00 V ±100.00 V

Range, dc V Source

110 mV +110.000 mV -10.000 mV

1.1 V +1.10000 V +0.10000 V

15 V +15.000 V +1.1000 V

Range, ohms Measure and Source

11 Ω 11.000 Ω 0.000 Ω

110 Ω 110.00 Ω 10.00 Ω

1.1 kΩ 1100.0 Ω 100.0 Ω

11 kΩ 11.000 kΩ 1.000 kΩ
