Fluke 744 [119/138] Dc voltage output

Documenting Process Calibrator

Specifications

109

DC Voltage Output

Range Resolution % of Output + % of Full Scale

1 Year 2 Year

110 mV 1 µV 0.01% + 0.005% 0.015% + 0.005%

1.1 V 10 µV 0.01% + 0.005% 0.015% + 0.005%

15 V 100 µV 0.01% + 0.005% 0.015% + 0.005%

Temperature Coefficient: (0.001% of output + 0.001% of f.s.)/°C in the ranges -10 to 18 °C and 28 to 50 °C

Maximum Output Current: 10 mA

Loading: (0.001% f.s. + 1 µV)/ mA

Common Mode Error: 0.008% f.s/(Common Mode Volt)

Maximum Input Voltage: 30 V dc
