744
Users Manual
4
Table 1. Summary of Source and Measure Functions
Function Measure Source
vdc V 0 V to +/-300 V 0 V to 15 V (10 mA max)
hac V 0 V to 300 V rms, 20 Hz to 5 kHz No sourcing
hFrequency 1 Hz to 1 kHz (100 mV to 300 V rms)
1 kHz to 30 kHz (0.5 V to 30 V rms)
30 kHz to 50 kHz (1 V to 30 V rms)
0.1 V to 10 V p-p sine wave, or peak square
wave, 0 Hz to 50 kHz
qResistance 0 Ω to 11 k Ω 0 Ω to 11 k Ω
mdc Current 0 mA to 110 mA 0 to 22 mA (28 V max), sourcing or sinking
qContinuity Beep and the word Short indicates continuity No sourcing
tThermocouple Types E, N, J, K, T, B, R, S, C, L, or U
tRTD 100 Ω Platinum (3926)
100 Ω Platinum (385)
120 Ω Nickel (672)
200 Ω Platinum (385)
500 Ω Platinum (385)
1000 Ω Platinum (385)
10 Ω Copper (427)
100 Ω Platinum (3916)
pPressure 27 modules ranging from 0 to 10 in. H
2
O
(2.5 kPa) to 0 to 10,000 psi (69,000 kPa)
Note
sLoop Power 24 or 28 V (22 mA max)
Note: Use an external hand pump or other pressure source as a pressure stimulus for the source pressure function.
