30
Preventing theft (Password Protect)
Once the setting is complete, press the [Menu]
button.
10
TIP
•When the time period has elapsed and the password is entered,
projection will start again, the "Time-elapsed" setting will be reset to
"0" and the countdown will start again.
•Make a note of the password so that you do not forget it and keep it
in a safe place.
•If you lose the remote control, you will not be able to enter the
password. Keep the remote control in a safe place at all times.
