92
Saving a User's Logo
Select "Yes" at the confirmation screen, and then
press the [Enter] button.
The image will then be saved. Once the image has been saved,
the message "Completed" will be displayed.
7
TIP
•Saving the user's logo may take a few moments (about 15 seconds).
Do not use the projector or any other sources which are connected to
the projector while the user's logo is being saved, otherwise it may
result in errors in projector operation.
•Once a user's logo has been saved, the logo setting cannot be
returned to the factory default.
