50
Using the Configuration Menu Functions
The configuration menus can be used to carry
out a variety of settings and adjustments.
The menus have a hierarchical structure, with a main menu that
is divided into sub-menus, which are further divided into other
sub-menus.
The remote control is used to operate the me
nus. Refer to "Using the Configuration Menus"
p.66 for details on using the menus.
Main menu
Sub-menu (Image)
