80
Problem Solving
Images appear dark
Nothing appears on the external monitor
Power does not turn on
Check
Remedy
Have the image brightness and luminance
been adjusted correctly?
Use the "Brightness" and "Brightness Control (EMP-74/54 only)" menu commands to adjust t
he
brightness and luminance.
"Image" - "Brightness" p.51, p.54
"Advanced" - "Brightness Control"
p.61
Has the image
contrast been adjusted
correctly?
Use the "Contrast" menu command to adjust the contrast.
"Image" - "Contrast" p.51, p.54
Is the lamp due for replacement?
When the lamp is nearly due for replacement, the images will become darker and the colour qua
lity
will become poorer. When this happens, the lamp should be replaced with a new one.
p.86
Check
Remedy
Are images from a port other than the
[Computer1/Component Video1] port being
projected?
The only images that can be displayed on an external monitor are those from the [Computer
1/
Component Video1] port.
p.21
Problems when projection starts
Check
Remedy
Have you pressed the [Power] button?
Press the [Power] button to turn the power on.
Are all of the indicators switched off?
The power cable is not connected correctly or power is not being supplied. Connect the po
wer cable
to the projector correctly.
p.32
Alternatively, check the circuit breaker to see if power is being supplied.
Do the indicators turn off and on when the
power cable is touched?
There is probably a poor contact in the power cable, or the power cable may be defective. Reinsert
the power cable. If this does not solve the problem, stop using the projector, disconnect the po
wer
cable from the wall outlet and contact the nearest address provided at "International Warra
nty
Conditions" in Safety Instructions/World-Wide Warranty Terms
booklet.
