65
Using the Configuration Menu FunctionsUsing the Configuration Menu Functions
"Reset All" Menu
Sub-menu
Function
Default
Execute
Resets all items in all menus to their default settings.
•Press the [Enter] button on the remote control to reset the
settings.
•Select "Reset" in an individual sub-menu such as the
"Image" or "Audio" menu to reset only the settings for the
items in each sub-menu.
•The "Input Signal", "User’s Logo", "Lamp Hours" and
"Language" settings will not retu
rn to their default values.
•If "Background Color" has been set to "Logo", the setting
cannot be returned to the default setting if the "User’s Logo
Protect" function of Password
Protect has been set to "ON".
-
