57
Using the Configuration Menu FunctionsUsing the Configuration Menu Functions
"Audio" Menu
Sub-menu
Function
Default
Volume
Adjusts the volume.
Median value
(10)
Audio
Input
Selects the input source (port) fo
r audio signals at the rear of
the projector.
The default setting varies de
pending on the type of signal
being input (for computer, RGB video and component video
input signals: Audio1; for video and S-Video input signals:
Audio2) Therefore, if audio
signals are being input to a
different port from the default port, you will need to select
the audio signal input source.
Depends on
connection
Reset
Resets all adjustment values
for the "Audio" menu functions
to their default settings.
•Press the [Enter] button on the remote control to reset the
settings.
•Select "Reset All" to return all settings for menus such as
"Image" and "Audio" to
their default settings.
p.65
-
TIP
The "Audio" menu settings are saved individually for each input signal source.
