Verto 50G138 [9/48] Operation settings
![Verto 50G138 [9/48] Operation settings](/views2/1569904/page9/bg9.png)
9
service workshop.
• Do not try to disassemble the charger. Entrust all repairs to an
authorized service workshop. Improper charger assembly may cause
electric shock or fire.
• Disconnect the charger from a power supply before starting any
maintenance or cleaning.
When the charger is not in use, it should be disconnected from the
power network.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and additional
safety systems are used, nevertheless there is always a small risk of
operational injuries.
CONSTRUCTION AND USE
Cordless screwdriver can be used with various driver bits of various
lengths with hexagonal shanks 6.35 mm (1/4”). The tool is designed
mainly as a screwdriver, it can also be used with sockets and drills with
hexagonal shanks (6.35 mm) for light drilling tasks (e.g. making of pilot
holes).
Cordless, battery-powered power tools are especially useful for works in
interior furnishing, adaptation of premises etc.
Use the power tool according to the manufacturer’s instructions
only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1. Bit socket
2. Switch button
3. Battery level indicator
4. Socket for charger
5. Button for battery level indicator
* Slight differences may appear between the product and drawing
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Charger - 1 pce
2. Drills - 3 pcs
3. Driver bits and drills - 20 pcs
4. Bit adaptor - 1 pce
PREPARATION FOR OPERATION
BATTERY CHARGING
Screwdriver is supplied with partially charged battery. It is recommended
that the first charging lasts for 5 hours.
Charging the battery should be made in temperatures between 4°C to 40°C.
New battery, or one that have not been used for a long time, will reach
full efficiency after approximately 5 charge/discharge cycles.
Insert the charger cord plug into the socket (4) in the screwdriver body.
• Connect the charger to mains socket (230V).
• Red diode (3) on the screwdriver casing will light up to indicate
charging process.
Diode will remain lit as long as the charger is connected to mains socket.
After discharge minimum 3 – 5 hours of recharge is required to reach the
maximum level of the battery.
Normal use allows for multiple chargings. To maintain the screwdriver in
good condition recharge its battery at least once per six months.
Do not charge the battery for more than 8 hours. Exceeding this time
limit may cause damage to battery cells.
Batteries heat up strongly when charging. Do not operate just after
charging – wait for the battery to cool down to room temperature. It
will prevent battery damage.
INSERTING / REMOVING WORKING BITS
• Place appropriate working bit in the screwdriver socket (1).
• Ensure the bit is inserted to the end and is properly installed.
Use additional magnetic adaptor supplied with the set when using short
driver bits. Always make a pilot hole before screwing screws with the
screwdriver.
SPINDLE BRAKE
Cordless screwdriver is equipped with electronic brake, which stops
the spindle immediately after the switch button is released. The brake
ensures precision when screwing or drilling and prevents free spindle
rotation after the tool is switched off.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF, CHANGE OF DIRECTION OF ROTATION
Cordless screwdriver is equipped with comfortably placed 2-position
switch button (2) (g. A), which enables easy change of direction of the
spindle rotation.
• Press upper half of the switch (2) to rotate the spindle clockwise.
• Press lower half of the switch (2) to rotate the spindle counter-
clockwise.
• Release the switch button pressure to stop the motor.
BATTERY LEVEL INDICATION
Screwdriver is equipped with signalisation of the battery level (LED diodes)
(3). Three diodes show the battery level. To check the battery level:
• Press the button (5).
• When all the diodes (3) (g. B) of the battery level indicator are lit, the
battery charge level is high.
• When red and yellow diodes are lit, the battery is partially charged.
• When only red diode is lit, the battery is discharged and must be recharged.
OPERATION AND MAINTENANCE
OPERATION AND MAINTENANCE
Screwdriver is a maintenance-free tool.
Clean the body with dry cloth. Do not use any cleaning agent, as it may
damage the tool body.
