KSB Amarex D 100-220/034 39100368 [33/52] Amarex n
![KSB Amarex D 100-220/034 39100368 [33/52] Amarex n](/views2/1584907/page33/bg21.png)
Extension elbow DN
3
DN 80/100
ISO 7005 PN16
DIN 2501 PN16
DN 80/100
ASME B16.1 class 125
4″
25
g
f
k
f
Z
f
x 19
D
f
Ø100
D
f
g
f
k
f
Z
f
x 19
DN
3
Dimensions of flanged bend DN
3
[mm]
Flange variant DN
3
g
f
k
f
D
f
Z
f
ISO 7005 PN16
DIN 2501 PN16
80 132 160 200 8
100 156 180 220 8
ASME B16.1 class 125 80 127 152,5 191 4
100 156 190,5 220 8
Waste Water
Submersible Motor Pump
Amarex N
33
