ATEX-compliant control units
The control units are not explosion-proof, which means
that they must not be operated in potentially explosive
atmospheres.
For ATEX-compliant variants, intrinsic safety barriers and
an ATEX level switch (float switch) must be fitted. Selection via
KSB EasySelect.
Valid for all countries except France.
Control unit accessories for Amarex N with ATEX
Item Description Power
min
[A]
Power
max
[A]
Type Mat. No. [kg]
LevelControl Basic 2 control unit for single-pump station
E20 Float switch, with master switch, 600 x 400 x 200 mm 2,5 4,0 BS1 400
DFEO
040 19073800 12
4,0 6,3 BS1 400
DFEO
063 19073801 12
6,3 10,0 BS1 400
DFEO
100 19073802 12
E21 Pneumatic, optional master switch, 400 x 281 x 135 mm 2,5 4,0 BC1 400
DPEO
040 19073771 4.5
4,0 6,3 BC1 400
DPEO
063 19073772 4.5
6,3 10,0 BC1 400
DPEO
100 19073773 4.5
E23 Bubbler control, with master switch, 400 x 300 x 155 mm 2,5 4,0 BS1 400
DLEO
040 19073821 12
4,0 6,3 BS1 400
DLEO
063 19073822 12
6,3 10,0 BS1 400
DLEO
100 19073823 12
E24 Bubbler control for BC version
Only to be used for connections with neutral conductors! Optional
component O1 (master switch) not possible! 400 x 281 x 135 mm
2,5 4,0 BC1 400
DLEO
040 19075154 4.5
4,0 6,3 BC1 400
DLEO
063 19075155 4.5
6,3 10,0 BC1 400
DLEO
100 19075156 4.5
LevelControl Basic 2 control unit for dual-pump station
E40 Float switch, with master switch, 600 x 400 x 200 mm 2,5 4,0 BS2 400
DFEO
040 19073842 13
4,0 6,3 BS2 400
DFEO
063 19073843 13
6,3 10,0 BS2 400
DFEO
100 19073844 13
E41 Pneumatic, optional master switch, 400 x 281 x 135 mm 2,5 4,0 BC2 400
DPEO
040 19073785 4.7
4,0 6,3 BC2 400
DPEO
063 19073786 4.7
6,3 10,0 BC2 400
DPEO
100 19073787 4.7
E43 Bubbler control, with master switch, 400 x 300 x 155 mm 2,5 4,0 BS2 400
DLEO
040 19073863 13
4,0 6,3 BS2 400
DLEO
063 19073864 13
6,3 10,0 BS2 400
DLEO
100 19073865 13
E44 Bubbler control for BC version
Only to be used for connections with neutral conductors! Optional
component O1 (master switch) not possible! 400 x 281 x 135 mm
2,5 4,0 BC2 400
DLEO
040 19075157 4.7
4,0 6,3 BC2 400
DLEO
063 19075158 4.7
6,3 10,0 BC2 400
DLEO
100 19075159 4.7
Only valid for France!
Control unit accessories for Amarex N with ATEX
Item Description Power
min
[A]
Power
max
[A]
Type Mat. No. [kg]
LevelControl Basic 2 control unit for single-pump stations
E20 Float switch, with master switch, 600 x 400 x 200 mm 2,5 4,0 BS1 400
DFEO
040 02
26) 26)
4,0 6,3 BS1 400
DFEO
063 02
26) 26)
6,3 10,0 BS1 400
DFEO
100 02
26) 26)
E21 Pneumatic, with master switch, 400 x 278 x 120 mm 2,5 4,0 BC1 400
DPEO
040 02
26) 26)
4,0 6,3 BC1 400
DPEO
063 02
26) 26)
6,3 10,0 BC1 400
DPEO
100 02
26) 26)
E23 Bubbler control, with master switch, 400 x 300 x 155 mm 2,5 4,0 BS1 400
DLEO
040 02
26) 26)
4,0 6,3 BS1 400
DLEO
063 02
26) 26)
6,3 10,0 BS1 400
DLEO
100 02
26) 26)
LevelControl Basic 2 control unit for dual-pump stations
E40 Float switch, with master switch, 600 x 400 x 200 mm 2,5 4,0 BS2 400
DFEO
040 02
26) 26)
4,0 6,3 BS2 400
DFEO
063 02
26) 26)
6,3 10,0 BS2 400
DFEO
100 02
26) 26)
41 Pneumatic, with master switch, 400 x 278 x 120 mm 2,5 4,0 BC2 400
DPEO
040 02
26) 26)
26)
See KSB Easy Select
Waste Water
Submersible Motor Pump
Amarex N
49
