Overview of product features
Standard designs
Size S impeller D impeller F impeller
Amarex N S 50-... Amarex N D 80-...
Amarex N D 100-...
Amarex N F 50-...
Amarex N F 65-...
Amarex N F 80-...
Amarex N F 100-...
Material variant G G G
Number of motor poles
2-pole 50-172/...
50-222/...
- 50-170/...
50-220/...
65-170/...
4-pole - 80-220/...
100-220/...
65-220/...
80-220/...
100-200/...
Explosion protection
Motor version UL Non-explosionproof
Motor version YL
11)
Ex d IIB T4 Gb
Motor version WL Non-explosionproof
Motor
Starting method
DOL
12)
Voltage 400 V
Cooling Cooled by surrounding fluid
Mode of operation S1: submerged (max. 25 m) (see
2)
in outline drawing)
S3: outside the fluid (see
1)
in outline drawing)
Power cable
Type Rubber-sheathed cable (H07RN8-F 7G1.5²)
Length 10 m
Cable entry Absolutely watertight
Sealing elements
Shaft seal Mechanical seal
Elastomer seals NBR
Monitoring equipment
Winding temperature version YL Temperature monitoring circuit (with automatic reset and start-up): bimetal switch directly
connected with the control circuit of the motor contactor
Limiting circuit (temperature limit for explosion protection without automatic reset): bimetal
switch connected via a tripping unit with manual reset
Winding temperature version
UL, WL
Temperature monitoring circuit (with automatic reset and start-up): bimetal switch directly
connected with the control circuit of the motor
Coating Environmentally-friendly KSB top coat (two-component epoxy paint), colour RAL 5002, film
thickness = 80 µm
Installation (⇨ Page 36)
Stationary, with guide hoop Installation depths 1.5 m/1.8 m/2.1 m
Stationary, with single guide rail Installation depth 4.5 m
Stationary, with twin guide rail Installation depth 4.5 m
Stationary, with guide wire Installation depth 4.5 m
Transportable Installation depth 4.5 m
Maximum temperature of fluid handled
Motor version UL 55 °C
Motor version YL 40 °C
Motor version WL 60 °C
11)
In countries stipulating explosion-proof units for handling sewage with faeces, motor version YL must be used.
12)
Maximum switching frequency: 30 starts per hour
Waste Water
Submersible Motor Pump
8
Amarex N
