Accessories for non-ATEX control units
Overview of control unit accessories for Amarex N, non-ATEX compliant
Item Description Mat. No. [kg]
E60 Float switch with free cable end (NO contact)
Switch housing made of polypropylene (max. fluid temperature
70 °C), circuit closed in upper float position, connection cable
(H07RN-F3G1)
3 m 11037742 0.5
5 m 11037743 0.8
10 m 11037744 1.3
15 m 11037745 1.8
20 m 11037746 2.4
25 m 11037747 2.9
30 m 11037748 3.4
E62 Float switch with free cable end (NC contact), Circuit open in
upper float position, power cable (H07RN-F 3G1)
5 m 11037756 0.8
10 m 11037757 1.4
20 m 11037758 2.6
E64 Leakage sensor F 1 3 m 19072366 0.2
E65 Open pressure bell set - pneumatic and bubbler control
with polyamide tube 8 x 1 mm
Tube length 10 m 19071721 1.2
Tube length 20 m 19071837 2
Tube length 50 m 19074200 2.5
E66
Closed pressure bell set - pneumatic
with polyamide tube 8 x 3 mm
Tube length 10 m 19071722 3.5
Tube length > 10 m
E70 Horn, 12 V DC, 105 dB, 150 mA, IP54, with 0.45 m connection cable 01086547 0.1
E71 Alarm combination, 12 V DC 01139930 0.1
E72 Yellow alarm strobe light, 12 V DC, 195 mA, IP65 01056355 0.3
E73 PC service tool 47121210 0.2
E90 Rechargeable battery retrofit kit for LevelControl Basic 2.
Powers the electronics, float switches, level sensor(s) or the
internal pressure sensor and the alarm equipment (buzzer, horn,
alarm combination), for single-pump and dual-pump stations.
For type BC, includes 2
rechargeable batteries
6 V, 1.3 Ah and charging
unit
19074194 0.8
E91 For type BS, consisting of
1 rechargeable battery
12 V, 1.2 Ah and
charging unit
19074199 1
Waste Water
Submersible Motor Pump
48
Amarex N
