KSB Amarex D 100-220/034 39100368 [51/52] Amarex n

Accessories for ATEX-compliant control units

Overview of accessories for Amarex N with ATEX

Item Description Mat. No. [kg]

E63 Float switch with free cable end

(NO contact)

With declaration of compliance with explosion protection

standards

Power cable (H 07 RN-F3G1)

5 m 01148226 0.7

10 m 01148247 1

20 m 01148248 2

E65 Open pressure bell set - pneumatic and bubbler control

with polyamide tube 8 x 1 mm

Tube length 10 m 19071721 1.2

Tube length 20 m 19071837 2

Tube length 50 m 19074200 2.5

E66 Closed pressure bell set - pneumatic

with polyamide tube 8 x 3 mm

Tube length 10 m 19071722 3.5

Tube length > 10 m

E70 Horn, 12 V DC, 105 dB, 150 mA, IP54, with 0.45 m connection cable, not explosion-proof 01086547 0.1

E71 Alarm combination, 12 V DC not explosion-proof 01139930 0.1

E72 Yellow alarm strobe light, 12 V DC, 195 mA, IP65, not explosion-proof 01056355 0.3

O45 Plastic housing, (W) 82 × (H) 55 × (D) 106.5 [mm], IP65, for easier installation of alarm

strobe light, for wall mounting

01061067 0.2

E73 PC service tool 47121210 0.2

E90 Rechargeable battery retrofit kit for LevelControl Basic 2. Powers

the electronics, float switches, level sensor(s) or the internal

pressure sensor and the alarm equipment (buzzer, horn, alarm

combination), for single-pump and dual-pump stations.

For type BC, includes 2

rechargeable batteries

6 V, 1.3 Ah and

charging unit

19074194 0.8

E91 For type BS, consisting

of 1 rechargeable

battery 12 V, 1.2 Ah

and charging unit

19074199 1

Waste Water

Submersible Motor Pump

Amarex N
