Yaskawa CIMR-UU4A0034A [128/644] Setting 2 conveyor application
![Yaskawa CIMR-UU4A0014A [128/644] Setting 2 conveyor application](/views2/1589210/page128/bg80.png)
u
Setting 2: Conveyor Application
Table 4.7 Conveyor: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Drive Duty Mode Selection 0: Heavy Duty (HD)
Table 4.8 Conveyor: User Parameters (A2-01 to A2-16)
No. Parameter Name
A1-02 Control Method Selection
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
No. Parameter Name
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
E2-01 Motor Rated Current
u
Setting 3: Exhaust Fan Application
Table 4.9 Exhaust Fan: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
b1-04 Reverse Operation Selection 1: Reverse Prohibited
C6-01 Drive Duty Mode Selection 1: Normal Duty (ND)
E1-03 V/f Pattern Selection F: Custom V/f Pattern
E1-07 Middle Output Frequency 30.0 Hz
E1-08 Middle Output Frequency Voltage
50.0 V
<1>
L2-01 Momentary Power Loss Operation Selection 1: Enabled
<1> Value shown is specific to 200 V class drives. Double value for 400 V class drives.
Table 4.10 Exhaust Fan: User Parameters (A2-01 to A2-16)
No. Parameter Name
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-04 Reverse Operation Selection
b3-01 Speed Search Selection at Start
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
E1-03 V/f Pattern Selection
E1-07 Middle Output Frequency
No. Parameter Name
E1-08 Middle Output Frequency Voltage
E2-01 Motor Rated Current
H1-05
Multi-Function Digital Input Terminal S5 Function
Selection
H1-06
Multi-Function Digital Input Terminal S6 Function
Selection
H1-07
Multi-Function Digital Input Terminal S7 Function
Selection
L5-01 Number of Auto Restart Attempts
4.6 Application Selection
128
YASKAWA ELECTRIC SIEP C710636 04C U1000 Industrial MATRIX Drive Technical Manual
