19
ENGLISH
2. Openthesystemllingtaplocatedonthehydraulicunitandwaituntil
waterbeginstodrainoutofthevalve.
3. Switch on the electricity supply to the boiler, leaving the gas tap turned
off.
4. Activate a heat request via the room thermostat or the remote control
panel,sothatthe3-wayvalvegoesintoheatingmode.
5. Activate a DHW request as follows: heat-only boilers connected to
anexternalstoragetank:activatethethermostatonthestoragetank;
6. Carry on with the sequence until only water leaks out of the manual
airventvalve,andtheairowhasstopped.Closethemanualairvent
valve.
7. Checkthesystempressureleveliscorrect(theideallevelis1bar).
8. Turnoffthesystemllingtap.
9. Turnonthegastapandignitetheboiler.
3.11 Flue gas discharge and air suction
Observelocallegislationregardinguegasdischarge.
Flue gases are discharged
from a centrifugal fan located inside the combus-
tion chamber and the
control board
constantly checks that this is working
correctly.Theboilerissuppliedwithouttheuegasdischarge/airsuctionkit,
since it is possible to use the accessories for appliance with a forced draught
sealedchamberthatbetteradaptstotheinstallationcharacteristics.
Foruegasextractionandtherestorationofboilercombustionair,itisessen-
tialtoonlyusecertiedpiping.Connectionmustbecarriedoutcorrectlyasin-
dicatedintheinstructionssuppliedasstandardwiththeuegas
accessories.
Multiple appliances can be connected to a single smoke pipe provided that
eachisasealedchamber-typeappliance.TheboilerisaTypeCappliance
(sealedchamber),andmustthereforehaveasafeconnectiontotheue
gasdischargepipeandtothecombustionairsuctionpipe;thesebothcarry
theircontentsoutside,andareessentialfortheoperationoftheappliance.
POSSIBLE OUTLET CONFIGURATIONS (FIG. 24)
B23P/B53P
Suction indoors and discharge outdoors
C13-C13xDischargeviaconcentricwalloutlet.Thepipesmayleavethe
boilerindependently,buttheoutletsmustbeconcentricorsufcientlyclose
together to be subjected to similar wind conditions (within 50 cm)
C23 Discharge via concentric outlet in common smoke pipe (suction and
discharge in the same pipe)
C33-C33x Dischargeviaconcentricroofoutlet.OutletsasforC13
C43-C43x Discharge and suction in common separate smoke pipes, but
subjected to similar wind conditions
C53-C53x Separate discharge and suction lines on wall or roof and in ar-
easwithdifferentpressures.Thedischargeandsuctionlinesmustnever
be positioned on opposite walls
C63-C63xDischargeandsuctionlinesusingpipesmarketedandcertied
separately (1856/1)
C83-C83x Discharge via single or common smoke pipe and wall suction line
C93-C93x Discharge on roof (similar to C33) and air suction from a single
existing smoke pipe
“FORCED OPEN” INSTALLATION (TYPE B23P/B53P)
Flue gas discharge pipe ø 80 mm (g. 20)
Theuegasdischargepipecanbedirectedtothemostsuitabledirection
accordingtoinstallationrequirements.Forinstallation,followtheinstruc-
tionssuppliedwiththekit.Inthisconguration,theboilerisconnectedto
theuegasdischargepipe(ø80mm)throughanadaptor(ø60-80mm).
In this case, the combustion air is picked up from the boiler instal-
lation room (which must be a suitable technical room with proper
ventilation).
Uninsulateduedischargeoutletpipesarepotentialsourcesofdanger.
Arrangetheuegasdischargepipesoitslopesby1%towardstheboiler.
The boiler automatically adapts the purging to the type of installation
andthelengthofthepipe.
“SEALED” INSTALLATION (TYPE C)
Theboilermustbeconnectedtoconcentricortwinuegasdischarge
pipesandairsuctionpipes,bothleadingoutdoors.Theboilermust not be
operatedwithoutthem.
Concentric pipes (ø 60-100 mm) (g.21)
The concentric pipes can be placed in the most suitable direction accord-
ing to installation requirements, complying with the maximum lengths in-
dicatedinthetable.
Arrangetheuegasdischargepipesoitslopesby1%towardsthe
boiler.
Non-insulatedoutletpipesarepotentialsourcesofdanger.
The boiler automatically adapts the purging to the type of installation
andthelengthofthepipe.
Do not obstruct or choke the combustion air suction pipe in any
way.
Forinstallation,followtheinstructionssuppliedwiththekit.
Vertical
straight length *
concentric pipe ø 60-100 mm
pressure drop
45° bend 90° bend
1,3 m 1,6 m
Horizontal
straight length *
concentric pipe ø 60-100 mm
pressure drop
45° bend 90° bend
1,3 m 1,6 m
*“Straightlength”meanswithoutbends,drainageterminalsorjoints.
If the boiler must be installed with drainage below, use the special elbow
(kitavailableonrequest–seePartsCatalogue).
In this type of installation, the inner pipe of the elbow must be cut at the
pointshowning.22toallowtheelbowitselftobeinsertedmoreeasily
intotheuegasdischargeontheboiler.
Concentric pipes (ø 80-125)
Forthisconguration,thespecialadaptorkitmustbetted.Theconcen-
tric pipes can face in the direction most suitable for installation require-
ments.Forinstallation,followtheinstructionssuppliedwiththespecic
condensingboilerskits.
straight length *
concentric pipe ø 80-125 mm
pressure drop
45° bend 90° bend
1,0 m 1,5 m
*“Straightlength”meanswithoutbends,drainageterminalsorjoints.
25R.S.I.5,85m
25R.S.I.6,85m
25R.S.I.15,3m
Twin pipes (ø 80 mm) (g. 23)
The twin pipes can face in the direction most suited to the installation re-
quirements.Forinstallation,followtheinstructionssuppliedwiththespe-
cicaccessorykitforcondensingboilers.
To use the combustion air suction pipe, one of the two inlets (A and B) must
beselected.Removetheclosureplugwhichisxedusingscrews,anduse
thespecicadaptorrelatingtotheinletselected(Cairinletadaptorø80-
Dairinletadaptorfromø60toø80)availableasanaccessory.
Arrangetheuegasdischargepipesoitslopesby1%towardsthe
boiler.
The boiler automatically adapts the purging to the type of installation and
thelengthofthepipes.Donotobstructorchokethepipesinanyway.
Refertothegraphstondthemaximumlengthsofthesinglepipe.
Theuseoflongerpipesreducestheboileroutput.
25R.S.I.45+45m
maximum straight length *
twin pipes ø 80 mm
*“Straightlength”meanswithoutbends,drainageterminalsorjoints.
pressure drop
45° bend 90° bend
1,0 m 1,5 m
maximumlength*oftheuegas
discharge pipe ø 80 mm
pressure drop
45° bend 90° bend
1 m
1,5 m
*“Straightlength”meanswithoutbends,drainageterminalsorjoints.
25R.S.I.70m
