ESIE-0302 Wiring Layout
Part 1 – System Outline 1–91
3
1
4
5
Components The table below describes the components.
Terminal Signal Connection
Wiring diagram
symbol
Description
X1
Digital
input
ID1-GND S10L Flow switch
ID2-GND _ _
ID3-GND S1HP
Q1D
K4S
High-pressure switch
Discharge protector
Overcurrent
ID4-GND S4LP Low-pressure switch
ID5-GND S9S Remote ON/OFF
Analog
input
B1-GND R3T Evaporator inlet water t°
B2-GND R4T Evaporator outlet water t°
B3-GND _ _
Y1-GND _ _
X2
Digital
output
C1/2-NO1 K1M Compressor on
C1/2-NO2 _ _
C3/4-NO3 KP Voltage-free contact for pump
C3/4-NO4 _ _
C5-NO5 H1P Alarm voltage-free contact
