ESIE-0302 Test Run and Operation Data
Part 4 – Commissioning and Test Run 4–45
3
4
5
1
2.3 Test Run and Operation Data for EUWA*5-24KZW1 and EUWY*5-24KZW1
Pressures The table below contains the measurable pressures.
Temperatures The table below contains the measurable temperatures.
Voltages The table below contains the measurable voltages.
Currents The table below contains the currents and used fuses.
Measurement Value
Suction pressure 4 – 8.5 bar
Discharge pressure 7 – 22 bar
Maximum water pressure 10 bar
Measurement Value
Leaving water temperature
■ Standard: 5– 20˚C
■ For ZH: -5 – 20˚C
■ For ZL: -10 – 20˚C
■ Heating: 35 - 50˚C (only for EUWY*5-24KZW1)
Outdoor temperature
■ -15 – 43˚C for standard unit
■ -10 – 43˚C for glycol unit
Temperature difference at the air side 10 – 15˚C
Temperature difference at the water side 3 – 8˚C
Discharge temperature 80 – 120˚C
Measurement Value
Power supply voltage Within ± 10% of the rated voltage
Phase imbalance Within ± 2% of the rated voltage
Control circuit voltage 230 V AC for main electromagnetic switches
24 V DC for the controllers
Unit Nominal current Maximum current Fuses
EUWAN5KZW1 7.7 A 11.2 A 3 x 20 gL/gG
EUWAP5KZW1 9.1 A 12.6 A 3 x 25 gL/gG
EUWAB5KZW1
EUWAN8KZW1 13.6 A 15.9 A 3 x 25 gL/gG
EUWAP8KZW1 15.0 A 17.3 A 3 x 25 gL/gG
EUWAB8KZW1
EUWAN10KZW1 15.9 A 18.9 A 3 x 25 gL/gG
