General Outline ESIE-0302
1–18 Part 1 – System Outline
3
1
1
4
5
(1)
: The table below contains the minimum water volume settings.
(2)
: The sound power level is an absolute value that does not depend on the surroundings or the
distance. It cannot be measured in the field (ISO 9614).
Model EUWAN24KZW1 EUWAP24KZW1 EUWAB24KZW1
Pump
No. x type __ 1 x Horizontal multi-stage end-suction
Model __ CH8-40
Nominal static height
pump
__ 191 kPa
Nominal static height
unit
__ 100 kPa
Hydraulic components
Buffer tank __ 55 l
Unit water volume 7 l 10 l 66 l
Expansion vessel __ 12 l
Pre-pressure
expansion vessel
1.5 bar
Safety valve __ 3 bar
Dimensions
(h x w x d)
1541 x 2580 x 734 mm
Weight
Machine weight 496 kg 514 kg 526 kg
Operation weight 503 kg 524 kg 592 kg
Casing
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
Material Polyester coated galvanised steel plate
Sound power level
(2)
81 dBA
Safety devices
■ Low-pressure switch
■ High-pressure switch
■ Pump motor overcurrent
■ Discharge temperature protection
■ Outlet water temperature protection
■ Compressor motor overcurrent relay
■ Fan thermal protector
■ Anti-recycling and guard timer
■ Digital display controller with electronic temperature control
■ Reverse phase protector
■ Flow switch.
Setting EUWA24KZW1
The minimum water volume for standard thermostat differ-
ence setting
3K
For reduced setting multiply this water volume by 3/new setting
Minimum allowable setting 0.1 K
