General Outline ESIE-0302
1–6 Part 1 – System Outline
3
1
1
4
5
(1)
: The table below contains the conditions for the technical specification values.
(2)
: The table below contains the minimum water volume settings.
(3)
: The sound power level is an absolute value that does not depend on the surroundings or the
distance (ISO 9614). It cannot be measured in the field
Dimensions
(h x w x d)
1345 x 856 x 630 mm 1290 x 1180 x 630 mm 1395 x 1330 x 630 mm
Weight
Machine weight 164 kg 224 kg 261 kg
Operation weight 166 kg 228 kg 266 kg
Casing
Material Polyester coated / galvanised steel plate
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
Sound power level
(3)
63 dB 66 dB 69 dB
Safety devices
■ Low-pressure switch
■ High-pressure switch
■ Evaporating temperature protection
■ Discharge temperature protection
■ Outlet water temperature protection
■ Compressor motor overcurrent relay
■ Fan thermal protector
■ Anti-recycling and guard timer
■ Digital display controller with electronic temperature control
■ Reverse phase protector
■ Internal fuses.
Al values are valid for an external
static pressure of...
with factory pulley setting...
5 HP 50 Pa _
8 HP 60 Pa 0 turns open.
10 HP 72 Pa 0 turns open.
Setting EUWAC5-10FZW1
The minimum water volume for standard thermostat difference setting 3 K
For reduced setting multiply this water volume by 3/new setting
Minimum allowable setting 0.1 K
Model EUWAC5FZW1 EUWAC8FZW1 EUWAC10FZW1
