Troubleshooting ESIE-0302
3–46 Part 3 – Troubleshooting
3
1
3
4
5
Sensors The table below contains the settings of the sensors.
Regulator The table below contains the settings of the regulator.
Code Parameter Function EUWY*5-24KZW1
Read/
write
13 Factory Air coil or ambient probe type 1 r/w
16 Factory Offset for /1 0˚C
17 Factory Offset for /2
18 Factory Offset for /3
1b Factory Digital filter 4
1v Factory Input limitation 8
1d User Measurement unit 0
Code Parameter Function
EUWY*5-
12KZW1
EUWY*16-
24KZW1
Read/
write
r1 Direct Cooling set point 12˚C 12˚C r/w
r2 Direct Cooling hysteresis 3˚C 3˚C
r3 Direct Heating set point 30˚C 30˚C
r4 Direct Heating hysteresis 3˚C 3˚C
r5 Factory Compressor rotation __ 0˚C
ra Factory Min. cooling set point Standard 7˚C 7˚C
ZL option -7˚C -7˚C
ZH option -2˚C -2˚C
rb Factory Max. cooling set point 25˚C 25˚C
rv Factory Min. heating set point 25˚C 25˚C
rd Factory Max. heating set point 48˚C 48˚C
