Ariston AXD 100 [12/88] Technical characteristics

ARGHERITA

Margherita - Instructions for installation and use

Model

AXD 100

Dimensions

width 59,5 cm

height 85 cm

depth 53,5 cm

Capacity

from 1 to 6 kg

Electrical

connections

voltage 220/230 Volt 50 Hz

maximum absorbed power 2300 W

Water

connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0,05 MPa (0,5 bar)

drum capacity 52 litre

Spinning speed

up to 1000 rpm

Control programs

in compliance

with IEC

regulation 456

programme 3; temperature 60°C; rinse level ; wash intensity ;

carried out with 6,0 kg load.

This appliance conforms with the following E.E.C. directives:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications

- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent modifications

The washing machine

does not drain or spin.

Does the selected

programme incorporates

water draining? Some

programmes stop at the end of

the wash cycles and draining

will have to be selected

manually.

Is the Easy iron" function

-where provided - enabled?

Complete the programme by

pressing the Select button.

Is the drain pump clogged?

To check it, turn off the water

supply, unplug the washing

machine and follow the

instructions on page 11, or call

for technical assistance.

Is the drain hose kinked?

The tract of the drain hose

must be as straight as possible.

Make sure the drain hose is not

squashed or kinked.

Is the washing machines

drain duct clogged? Is there

an extension of the drain

hose? If so, is it positioned

incorrectly, blocking the water

flow?

Excessive vibration

during the spin cycle.

Have all transit screws been

removed durind instal-

lation? See the following

page on installation

procedures.

Has the washing machine

been levelled correctly? The

levelling of the appliance

should be checked

periodically. Adjust the feet

and check them with a level.

Is there space between the

machine and adjacent units?

If it is not a built-in model, the

washing machine will oscillate

a bit during the spin cycle. A

few cm of space should

therefore be left around it.

The washing machine

leaks.

Is the metal ring of the inlet

hose properly attached? Turn

off the water supply, unplug

the appliance and try

tightening its attachment

without forcing it.

Is the detergent dispenser

obstructed? Remove and

wash it under tap water.

Is the drain hose well

attached? Turn off the water

supply, unplug the appliance

and try tightening its

attachment.

Too much foam.

Is the detergent appropriate

for machine washing? Check

whether the definition on its

label reads for machine wash

or hand and machine wash,

or any other similar wording.

Is the correct amount being

used? An excessive amount of

detergent, besides producing

too much foam, does not

guarantee a more effective

wash, and causes scaling in the

internal parts of the appliance.

If, despite all checks, the

washing machine fails to

function and the problem

persists, call your nearest

authorised Customer Service

Centre, providing the following

information:

- the nature of malfunction

- the model type no. (Mod. ....)

- the serial number (S/N ....)

This information can be found on

the data plate situated at the back

of the washing machine.

Technical characteristics

Always get

assistance from

authorised

technicians and

always insist on

original spare

parts.
