The Digital Controller ESIE07-04
2–52 Part 2 – Functional Description
3
1
2
4
5
HP alarm settings This screen allows you to set the high pressure alarm settings.
LP alarm settings This screen allows you to set the low pressure alarm settings.
LP alarm delay This screen allows you to set the low pressure alarm delay timers
Pressure ratio
alarm
This screen allows you to set the pressure ratio alarm setpoints.
Remark : The actual pressure ratio alarm setpoint will be calculated according to the actual
compressor capacity.
P Setpoint : High pressure alarm setpoint to activate high pressure alarm
P Diff. : High pressure alarm differential to be able to reset high pressure alarm (setpoint –
diff.)
Transducers High Pressure Alarm
Setpoint 20.0 bar
Diff. 05.0 bar
P Setpoint : Low pressure alarm setpoint to activate low pressure alarm
P Diff. : Low pressure alarm differential to be able to reset low pressure alarm (setpoint +
diff.)
Transducers Low Pressure Alarm
Setpoint 01.2 bar
Diff. 00.1 bar
P Start-Up Delay : Low pressure bypass timer during start-up of compressor
P Run Delay : Low pressure delay time before unit goes into LP alarm when unit is in oper-
ation
Low Press. Alarm Delays
Start-Up Delay :
Run Delay :
060 s
040 s
P Min Load Setp : Pressure ratio alarm setpoint when compressor is operating at minimum load
P Max Load Setp : Pressure ratio alarm setpoint when compressor is operating at full load
Pressure Ratio Alarm
Min Load Setp
Max Load Setp
1.4
1.8
